Townsend Labs Inc Sphere L22

£1,379.00 Available to Order

Townsend Labs Inc Sphere L22

RRP £1,559.00 Save £180.00

£1,379.00

Available to Order

Place your order today and we will email you when we have an estimated delivery date.

Includes 30-Day Exchange & 3-Year Warranty

Buy with confidence: We're the 1st, and only, UK guitar retailer to offer a 3-year warranty & 30-day exchange as standard.

Notify me when in stock

We'll share some similar product recommendations, and if the item does not come back in stock we will let you know.

Manufacturer's ID: SPHERE-L22

The Sphere L22 microphone system from Townsend Labs models the characteristics of the most sought-after large-diaphragm condenser microphones with amazing accuracy and allows selection of different mics and patterns even after tracking.

The Sphere L22 system consists of a dedicated, dual-channel microphone and its software counterpart, the included Sphere plug-in (UAD, AAX DSP, AAX Native, VST, AU). The exacting models incorporate transient response, harmonics, proximity effect, and multi-dimensional polar response. Thanks to Townsend Labs' exhaustive and curated study of classic microphones, the Sphere system currently brings the soul of 34 of the world's most revered microphones to life. The striking accuracy and sonic results have convinced owners from home recordists to seasoned industry veterans, such as Joe Chiccarelli, Billy Bush, and Allen Sides.

Now You Can

  • Record with a world-class microphone collection of 34 stunning-sounding mics
  • Change mic type, polar pattern, and other microphone characteristics, even after tracking!
  • Audition the sound of different microphones without tiring the artist
  • Reduce coloration and room ambience in challenging spaces in combination with popular isolation
  • filters, such as the sE Reflexion Filters, Aston Halo, Kaotica Eyeball, and more.
  • Record in stereo from a single microphone

Breakthrough Microphone Modeling Technology

Sphere’s multi-dimensional approach captures the spatial nuances, proximity effect, and off-axis frequency response of a wide range of microphones, which until now was not possible with any other product

Dream Collection

Access some of the most prized microphones of all time, including a 47 (with VF14 tube), a 67, an M49, a C12, and the 800.

Sphere L22 Microphone

The Sphere system employs the high-resolution, dual-channel L22 large-diaphragm condenser microphone, custom-designed to capture the three-dimensional soundfield with exacting detail. Manufactured to extremely tight tolerances, the L22 ensures that modelling is consistent and accurate.

Realtime UAD and AAX DSP Processing

With Universal Audio Apollo interfaces, achieve extremely low latency (approx. 1.6ms round trip at 96kHz) for guaranteed real-time performance. The AAX DSP format allows for guaranteed low-latency performance on Avid HDX systems. UAD and AAX DSP plug-in formats are included at no additional cost. Sphere also supports native AAX, VST and AU plug-in formats.

Dual Mic Models

Dual Mode in the Sphere plug-in makes possible phase-coherent mixing of multiple virtual mic models from the same physical microphone, before or after tracking. It's also possible to adjust the relative phase alignment of the two mics with the Align control.

IsoSphere™

Microphone isolation filters (also referred to as reflection filters or portable acoustic booths) are a boon to home recordists, but they also impart their own undesirable colouration to the sound, and their effectiveness at reducing reflections and background noise is limited, especially at low to mid frequencies. IsoSphere™ optimizes how the Sphere L22 works together with commonly-available isolation devices—such as the sE Reflexion Filters, Aston Halo, Kaotica Eyeball, and even vocal booths. It enhances off-axis behavior for maximum rejection and modifies frequency response to compensate for unwanted colouration, leading to even better-sounding recordings.

Polar Meter

The Sphere plug-in features a visually informative (and very cool) Polar Meter that dynamically displays the direction and level of sound being picked up by the microphone, as well as the currently selected polar pattern.

Off-Axis Correction™

Create more accurate polar patterns to reduce bleed, room coloration, and susceptibility of feedback before or after tracking. For more information, see the Off-Axis Correction chapter in the Sphere Hardware and Software User Guide.

Low Noise

The microphone hardware has a self-noise level of 7dB-A SPL, well below most vintage microphones and comparable to many of the best modern microphones.

High SPL Handling

The L22 can handle in excess of 140dB SPL before clipping and is remarkably rugged. It won’t be damaged by high SPLs or air blasts as some vintage microphones can be.

Specification

Equivalent Noise Level 7 dB-A
Max SPL at 0.5% THD 140dB (with -20dB pad engaged)
Pad Attenuation -10db and -20dB
Sensitivity 22 mV/Pa
Output Connector 5-pin male XLR
Breakout Cable 10’ (3m) 5-pin female XLR to dual 3-pin male XLR
Weight (mic only) 1.7 lbs. (770 grams)
Dimensions (mic only) 8.9" x 2.5" (225mm x 63mm)
Output Impedance 200 Ohms
Recommended Load Impedance >1000 Ohms
Phantom Power Voltage: 44 to 52 V per channel
Current: 5 mA per channel typical, 8 mA at max SPL
Sphere® Core Plug-In
Supported Plug-in Formats UAD
AAX DSP
AAX Native
VST2
VST3
Audio Units (Mac only)
Supported Operating Systems Native (AAX, VST and AU):
Mac OSX 10.8.5 and above
Windows 7 and above

Apollo Interfaces and UAD-2 hardware (AAX, VST, AU, and RTAS)
Mac OSX 10.9.5 and above
Windows 7 and above
System Requirements 4 GB of RAM
200 MB free disk space
1024 x 768 display resolution
Internet connection to download software
Two microphone preamplifiers with phantom power
Compatible plug-in host application (DAW) software supporting AAX, VST2, VST3, AU or UAD.
34 Included Microphone Models LD-47K
LD-49K
LD-67
LD-67 NOS
LD-12
LD-251
LD-800
LD-87 Vintage
LD-87 Modern
LD-87 TK
LD-37A
LD-37P
LD-414 Brass
LD-414 Nylon
LD-414 US
LD-414 T2
LD-563
LD-017T
SD-451
SD-416
RB-4038
RB-77DX Satin
RB-77DX Umber
DN-57
DN-7
DN-20
DN-409N
DN-409U
DN-421N
DN-421S
DN-421B
DN-12A
DN-12E
Sphere Linear
