Strymon PCH-1 Stereo Active Direct Interface

£259.99

Pre-Order

Pre-order this now and we will deliver it to you when it becomes available.

Includes 30-Day Exchange & 3-Year Warranty

We're the first and only UK guitar retailer to offer a 3-year warranty & extended 30-Day exchange as standard.
Buy with confidence today.

Notify me when in stock

We'll share some similar product recommendations, and if the item does not come back in stock we will let you know.

Frequently Bought Together


Total Price: £

Manufacturer's ID: PCH-1

PCH is an ultra-premium stereo active direct interface with a hidden superpower - an on board console-quality headphone amplifier. Now you can rest easy knowing that the sound of your pedalboard won’t change even a little when passing through PCH, and the headphone amp means you won’t have to ask anyone how you sound. You’ll know.PCH has a recording console-quality headphone amplifier onboard, making it easy to monitoror practice listening to the sound of your entire rig or pedalboard in full stereo, no matter the pedal order or the components.No matter what instrument or genre of music you play, if you need to connect unbalanced outputs to a PA, recording interface or flat response speaker system, PCH is the ultimate choice for an absolutely transparent stereo direct interface - and it’s the only one that you can listen to locally via the headphone amp.

PCH was designed from the ground up to be sonically transparent, virtually unclippable and bulletproof - it’s the ultimate solution for your pedalboard, keyboard rig or synth setup

Specification

  • Two channel design - use in stereo or dual mono, whichever fits your setup
  • Runs on 9VDC - internally converted to 24V to be virtually unclippable
  • Onboard headphone amplifier powerful enough to drive high impedance headphones
  • Switchable Mic/Line level operation for the XLR outputs
  • Defeatable ground lift for the XLR outputs
  • Defeatable Sum for the Thru outputs
  • Internal supply uses custom transformer for galvanic isolation
  • Basically, PCH runs off of a modified internal mini Ojai power supply
  • Flat frequency response
  • Extremely low THD (Total Harmonic Distortion)

Construction

  • Thick 3mm extruded aluminum external shell with 5mm ribs for bulletproof protection.
  • Shell awning design protects headphone volume pot while allowing easy access to jacks.
  • High quality long life jacks and switches
Input Impedance 1 MΩ
Max Input Level +20dBu
Thru Output Impedance 100Ω
SNR +135dB (A-Weight)
Noise Floor -115dBV (10-22kHz no A-Weight)
Gain Relative to Inputs +0dB
Frequency Response +/- 0.25dB, 10Hz - 80kHz+
HP Output Impedance
Frequency Response +/- 0.25dB, 10Hz - 80kHz
XLR, Line Setting
Output Impedance 275Ω
SNR +130dB (A-Weight)
Noise Floor -110dBV (10-22kHz no A-Weight)
Gain Relative to Inputs +0dB
Maximum Output Level +20dBu
Frequency Response +/- 0.25dB, 10Hz - 80kHz+
XLR, Mic Setting
Output Impedance 100Ω
Gain Relative to Inputs -20dB
Maximum Output Level +0.0dBu
SNR +125dB
Noise Floor -125 dBV (10-22kHz no A-Weight)
Frequency response +/- 0.25dB, 10Hz - 80kHz+
Power Supply
Input Voltage 9VDC
Current Requirement 500mA
