Palmer PAN 02 Active DI Box

£69.00 In Stock

Delivery Tomorrow

Click and Collect available

Palmer PAN 02 Active DI Box

RRP £81.94 Save £12.94

£69.00

In Stock

4 Available

Order before 1PM for Delivery Tomorrow

Includes 30-Day Exchange & 3-Year Warranty

Buy with confidence: We're the 1st, and only, UK guitar retailer to offer a 3-year warranty & 30-day exchange as standard.

Delivery Tomorrow

With 1 hour Delivery slot

Click & Collect

Live Stock levels from all our stores.

Store
Availability
Edinburgh
In Stock, Collect Today
Glasgow
In Stock, Collect Today
Newcastle
Collect on Wednesday
Birmingham
Collect on Wednesday
Epsom
In Stock, Collect Today
Camden
In Stock, Collect Today

Frequently Bought Together


Total Price: £

Manufacturer's ID: PAN 02

Standard active DI box. Can be operated with 9 V batteries or 48 V phantom power. High-impedance input; higher output level than with a passive DI box. Active circuitry allows for high input impedance ( 1 meg. ohm) and higher input sensitivity (typical difference between in and out -4 dB). Maximum output impedance with phantom power operation +10 dB. Output: transformer balanced. The special "floating ground" circuitry enables ground lift even during phantom power operation. Metal case 110 x 73 x 42 mm.

Specification

Type active
Channels 1
Inputs 1
Input connectors 6.3 mm jack
Max. input level + 45 dBu
Input impedance (@ 60 Hz) 1 M Ohm(s)
Input pad 0 / -30 dB
Outputs 1
THRU outputs/channel 1
Output connectors 6.3 mm jack, XLR
Max. output level + 10 dBu
Output impedance 600 Ohm(s)
Frequency response 10 - 20000
Transformer balanced Yes
Ratio 1 : 1
Controls attenuator, ground lift
Operating voltage +48 V phantom power, 9 V block
Power consumption 3.8 mA (9V), 4 mA (48V)
Cabinet material sheet steel
Cabinet surface Powder coated
Width 110 mm
Depth 73 mm
Height 42 mm
Weight 0,353 kg

Customer reviews

Overall Rating 5/5 (2 reviews)

Joe A. - 21/5/2020

Palmer make stuff that works perfectly, is built like tank, and reasonable. What's not to like.

EA M. - 10/6/2017

Show more reviews
