Eventide Mixinglink Mic Pre with FX Loop Pedal

£440.00

In Stock

Order now for FREE Delivery on Thursday

Includes Extended Exchange & 3-Year Warranty

We're the first and only UK guitar retailer to offer a 3-year warranty & extended Christmas Exchange as standard.
Buy now and exchange until 31st January 2025

Buy Now, Pay 2025

  • No Deposit
  • Pay nothing for up to 12 months
  • Apply in minutes
Apply Now

FREE Delivery on Thursday

With 1 hour Delivery slot

Click & Collect

Live Stock levels from all our stores.

Store
Availability
Edinburgh
Collect on Saturday
Glasgow
Collect on Saturday
Newcastle
Collect on Saturday
Birmingham
Collect on Saturday
Epsom
Collect on Saturday
Camden
Collect on Saturday

Frequently Bought Together


Total Price: £

Manufacturer's ID: MIXINGLINK

What we say:

At A Glance:

The Eventide MixingLink is a super-powerful unit that really opens up a whole world of versatility to your performances. Feel like running your vocals or horns through the huge array of effects pedals out there? Easy! Want to switch between more than one instrument? Done! Send your signal to more than output, like the PA, desk or a couple of amps at once? No Problemo!

With its 48v Phantom Power Circuit and up to 65dB of clean gain, the MixingLink comports itself as a fantastic mic-pre that works fantastically with any kind of mic, and thanks to its array of balanced ins and outs can send that signal wherever you like, straight to the PA, mixing desk, your DAW, your amp, even headphones!

Features We Love:

Mic-Pre

This powerful device is fantastic for use with a whole range of mics including condensers and ribbons thanks to its 48v Phantom Power circuit and up to 65dB of clean gain.

FX Loop

The inclusion of the FX Loop in the MixingLink means you can create sounds you've only before dreamed of, and do it the easy way using your existing XF pedals! The balanced I/O connection ensure you can run any mic or instrument through your chosen pedals without any impedance issues. The Mix controls also allow you to select between a 100% Dry signal with FX blended in, Mic/FX Balance, and 100% FX (No Dry) modes.

Personal Mixer

With its array of Input and Output connections, the MixingLink can even operate as an A/B box  for multiple instrument-in or amp-out setups, and especially makes itself indispensable as DI to run straight to your desk, DAW or PA system, or as a headphone amp for practice or personal monitoring, or as an output to your choice of amp - or all of the above!

Who Is This For?

Experimental performers who want to mix vocals or horns with standard FX pedals will relish this unit, as well as anyone looking for a versatile solution to onstage A/B mixing of multiple Ins or Outs.

Highlights:

  • Super versatile onstage mixer
  • Serves as a powerful, high quality Mic-Pre
  • 48V Phantom Power
  • Up to 65dB of Clean gain
  • A/B Splitter

Specification

Ultimate Versatility

  • Latching or momentary footswitch control of FX loop for performance effects
  • Works with a wide range of microphones including condenser and ribbon mics with up to 65dB of clean gain
  • Aux I/O connection supporting stereo input and send
  • Guitar amp output and headphone monitor output with separate master volume control
  • International universal power supply included
  • Operates on 9V battery (no phantom power when operating on a battery)
  • 48V phantom power for condenser mics
  • Balanced XLR output which supports DI and line levels
  • Instrument and balanced line level inputs
  • Versatile mix control supports 3 modes
  • 100% Dry w/FX blended in
  • Mic/FX balance control
  • 100% FX (no Dry)

INPUTS

Analog Input MAX Input Levels, Input Impedance
INST IN +10dBu, 500kΩ
1/4″ Line IN +24dBu, 22kΩ
Out 2 +4dBu, 2kΩ
EXP +10dB, 200kΩ
AUX IN +4dBu, 5.0kΩ

OUTPUTS

Analog Output MAX Output Levels, Output Impedance
TO FX +10dBu, 400Ω
TO AMP +10dBu, 250Ω
PHONES 150mW per channel, min Load - 8 Ohms
DI/LINE OUT (DI) -10dBu, (LINE) +18dBu, 200Ω
AUX OUT 18mV, 200Ω (mobile mic level)

DEVICE SPECIFICATIONS

Power Supply 9V DC @ 200mA / Center Negative (-), 5.5mm/2.1mm jack (BOSS standard)
Dimensions 3.6” (H) x 2.65” (W) x 1.5” (D) / 91mm (H) x 67mm (W) x 38mm (D)
Weight .96 lb / .43 kg
