Moog Sub Phatty

Specification

Say hello to the Sub Phatty, the grittiest Moog Synth ever.
“We set out to design the grittiest Moog synth ever, one that still offers all of the great sound and flexibility that Moog synthesizers are known for, but that also really has teeth,” said Mike Adams, President of Moog Music. “One of the great advantages of the Sub Phatty is its ability to conjure aggressive sounds that cut through a dance mix, stand out on-stage, or burn up the studio. We think that everyone from producers and sound designers to DJs and synthesists will have a blast using it.”

Moog Music’s engineers have crafted the Sub Phatty’s oscillators to perform with extreme accuracy and require almost no warm-up time. Just power up, dial in your settings, and put your fingers to work on the keys to summon crisp and detailed waveforms, a vibrant and articulate sound that more than honors the rich sonic density synonymous with Moog creations.

The Sub Phatty is the first analog synth to feature Moog’s transformative new Multidrive section; at low settings Multidrive adds warmth and girth, but when pushed, it delivers a screaming snarl that is highly reactive to resonance, waveshape, and oscillator level. Experiment with this new circuit and unlock an undiscovered world of vivid analog tonalities.

The mixer section offers innovations of its own, including a sub oscillator that outputs a square wave one octave below Oscillator 1. Use this powerful tool as a third oscillator for added depth, or to craft your own customized incarnation of monstrous Moog bass. Also in the mixer section is a noise generator voiced to deliver low-frequency content, rich with body and punch. If your goal is to sculpt analog percussion and sound effects, look no further.

The Sub Phatty features a wide range of parameters just below the surface, and all features are easily accessible from the instrument’s front panel, or via the free standalone/plugin editor. Select filter poles, assign wave mod destinations, or specify pitch bend amounts — it’s all there.

The Sub Phatty brings a fearless new voice to the Moog family of synthesizers. With its streamlined interface and dynamic sound design flexibility, this new synth fuses an unparalleled connection between human & machine, opening the door to unprecedented sonic exploration.


Moog Sub Phatty

• Sound Engine: Analog
• Number of Keys: 25
• Type of Keys: Semi-Weighted
• Other Controllers: Pitch Bend, Mod Wheel
• Polyphony: Monophonic

Synthesizer

• Sound Sources: 2 Variable Waveshape Oscillators, 1 Square Wave Sub Oscillator, 1 Noise Generator
• Oscillator Calibration Range: 22Hz-6.8KHz.Guaranteed note range at 8’ of Note 18 to 116
• Mod Sources: Triangle, Square, Saw, Ramp, SH, Filter Envelope
• Mod Destinations: Pitch, Osc 2 Pitch Only, Filter, Waveshape
• Transposition: +/- 2 Octaves

Inputs and Outputs

• Audio Input: 1xTS
• Audio Output: 1xTS, 1xTRS Headphone
• MIDI I/O: DIN In, Out, and MIDI over USB
• CV/Gate Inputs: Filter CV, Pitch CV, Volume CV, KB Gate

What's In The Box

• Moog Sub Phatty
• Power Supply
